METAL PERMANENT APPLICATION SPRING LOADED CLIPS
REF. | Remarks | F | F1 | ØR | ØR1 | Ød | h | h1 | Form | ? |
080523 | 080523 | 3 | 1 | 9 | 7...8 | 15 | 3 | 20 | 1 | |
080569 | 080569 | 4,5...5 | - | 6 | - | 11.75 | 3 | 13 | 1 | |
080511 | 080511 | 3 | 0.8 | 6.5 | 4.5 | 11.5 | 2.5 | 20.5 | 1 | |
080510 | 080510 | 6 | 0.8 | 7.5 | 6 | 11.5 | 2.5 | 24 | 1 | |
080623 | 080623 | 0.75 | 2,2...3 | 6.5 | - | 13 | 1.2 | 17 | 2 | |
080570 | 080570 | 3...3,5 | - | 6.1 | - | 13 | 1.5 | 17 | 2 | |
080585 | 080585 | 2,8...3,6 | 0,75...1 | 6.5 | - | 13 | 1.5 | 17 | 2 |
