TWIN - U - CLIPS
REF. | Remarks | F | F1 | l | b | l1 | h | h1 | h2 | s | Form | ? |
017988 | 017988 | 2 | 1,4...1,6 | 5 | 20 | 1.6 | 7.9 | 15.8 | 6.4 | 0.4 | 1 | |
052047 | 052047 | 0,8...1,4 | 2...3 | 3.2 | 13 | 1.6 | 9 | 9 | 9 | 0.4 | 1 | |
055536 | 055536 | 2...2,3 | 2...2,3 | 2.4 | 12.75 | 2.4 | 10.5 | 10 | 9 | 0.4 | 1 | |
017194 | 017194 | 0.5 | 4...5 | 9 | 10 | 1.2 | 14.2 | 13.5 | 10 | 0.5 | 1 | |
203184 | 203184 | 0.7 | 1,7...1,9 | 1.6 | 25 | 2.2 | 17.2 | 16.6 | - | 0.55 | 1 | |
017375 | 017375 | 1...1,2 | 9 | 9.2 | 15 | 1.3 | 7.4 | 8.1 | 12.4 | 0.6 | 1 | |
014559 | 014559 | 1,5...2 | 1,5...2 | 2 | 38 | 2 | 10.5 | 9.5 | 9 | 0.4 | 2 | |
011891 | 011891 | 0,75...1 | 2...2,3 | 2.4 | 12.5 | 2.3 | 10 | 9 | 8.5 | 0.5 | 2 | |
054303 | 054303 | 2,5...3 | 1,8...2 | 3.2 | 13 | 2.2 | 9.4 | 9.4 | 9.4 | 0.4 | 2 | |
011871 | 011871 | 2.5 | 1.25 | 2.75 | 12.75 | 1.75 | 10.2 | 8.7 | 12.2 | 0.5 | 2 | |
011865 | 011865 | 0,75...1 | 1...1,5 | 1 | 13 | 2 | 10 | 9.25 | 12.5 | 0.5 | 2 | |
151456 | 151456 | 1...2 | 1 | - | 20 | - | - | - | - | 0.5 | 3 | |
013502 | 013502 | 1,8...2 | 1 | 2.3 | 20 | 1.6 | 14 | 14 | 12 | 0.5 | 3 | |
013630 | 013630 | 0,9...1,1 | 2,25...2,75 | 1.5 | 20 | 3.8 | 21 | 18.5 | 11.5 | 0.5 | 3 | |
019057 | 019057 | 0,7...1,2 | 0,7 .. 2 | 2.5 | 15 | 1.7 | 13.3 | 11.4 | 12 | 0.5 | 3 | |
012895 | 012895 | 2.5 | 5,8...6,1 | 3.8 | 20 | 6.3 | 21 | 11.5 | 14 | 0.5 | 4 | |
011516 | 011516 | 0,75...1,25 | 2...2,3 | 2.4 | 12.5 | 1.4 | 10 | 9 | 10 | 0.4 | 4 | |
020790 | 020790 | 1...1,8 | 2...3,2 | 3.5 | 20 | 2 | 15.6 | 14 | 15.6 | 0.6 | 4 | |
013698 | 013698 | 0,8...1,5 | 0,5...1,5 | 2 | 12.75 | 1.6 | 14 | 8 | 14 | 0.4 | 4 | |
016662 | 016662 | 0,9...1,1 | 3,9...4,1 | 6.4 | 18 | 3 | 20.8 | 28 | 31.5 | 0.8 | 5 | |
