VARIABLE DIAMETER
REF. | Remarks | ØD1/L1xH1 | F | ØR | l x b | h | h1 | e | Form | ? |
055064 | 055064 | 10...15 | 0,6...4 | 6,5...6,7 | 22 x 7,5 | 26.6 | 7 | - | 1 | |
054753 | 054753 | 22...34 | 0,7...2,5 | 6,35...6,55 | 52 x 20 | 47,85...49,65 | 7,2...9 | - | 2 | |
015441 | 015441 | 6...8 | 0,8...6 | 6,5...6,7 | 29 x 9 | 18.8 | 10.5 | - | 2 | |
015063 | 015063 | 6...8 | 0,8...6 | 6,5...6,7 | 29 x 9 | 20 | 10.8 | - | 2 | |
014764 | 014764 | 5...16 | 12...13 | 17...17,2 | 38 x 9 | 25 | 25 | - | 2 | |
014252 | 014252 | 7...21 | 0,65...1,8 | 6,3...6,8 | 38 x 9 | 28.7 | 7.3 | - | 2 | |
015566 | 015566 | 7...21 | 0,5...4 | 6,5...6,7 | 38 x 9 | 29 | 7.5 | - | 2 | |
019554 | 019554 | 8...11 | 1...13 | 7...7,4 | 26 x 10 | 17 | 18.2 | - | 2 | |
017856 | 017856 | 12...15 | 1...6 | 6,5...6,7 | 24,5 x 14 | 22.5 | 10.5 | - | 2 | |
016633 | 016633 | 10...24 | 0,8...3,5 | 6,5...6,7 | 35 x 10 | 49,1...51,8 | 7,6...10,3 | - | 3 | |
015705 | 015705 | 5...20 | 1,2...1,8 | 6,3...6,8 | 33 x 9 | 38,2...38,8 | 7,7...8,3 | - | 3 | |
016007 | 016007 | 5...20 | 0,8...3,5 | 6,5...6,7 | 35,4 x 9,2 | 39,9...42,6 | 7,8...10,5 | - | 3 | |
016197 | 016197 | 6...8 | 0,8...6 | 8...8,2 | 18 x 9 | 29.2 | 10.5 | - | 3 | |
016008 | 016008 | 6...8 | 0,8...6 | 6,5...6,7 | 17 x 9 | 29.2 | 10.5 | - | 3 | |
015997 | 015997 | 10...36 | 0,8...3,5 | 6,5...6,7 | 39 x 20 | 55,6...58,3 | 7,6...10,3 | - | 3 | |
018877 | 018877 | 38 x 55 | 2,5...3,5 | 6,5...6,7 | 45 x 15 | 73,1...74,1 | 9,3...10,3 | - | 3 | |
152192 | 152192 | 6...13 | 0,7...1,7 | 6.7 | 38,5 x 12 | 26.5 | 7 | - | 4 | |
016768 | 016768 | 3...7,5 | 0.75 | 6,3...6,5 | 37,5 x 12 | 16.45 | 7.5 | 24 | 5 | |
108141 | 108141 | 3...14 | 0,7...1,5 | 8.3 | 34 x 19 | 15 | 6.5 | - | 6 | |
208227 | 208227 | 3,0...15,0 | 0,7...6,0 | 6.7 | 27,29 x 20 | 22.85 | 10.67 | - | 7 | F |
